10'' Offset Flush Bolt, Heavy Duty Brass - Choose Finish

Part Number: 362300-AB Price: $65.61
COLOR: - Antique Brass

Measurements:
10 inch Heavy Duty Offset Flush Bolt
Bolt Length: 10 inch
Bolt Width: 5/8 inch Diameter Half Round Rod
Bolt Offset: 5/8 inch
Guide Width: 1-1/2 inch
Guide Projection: 9/16 inch
Knob Diameter: 1-1/4 inch
Bolt Throw: 1-1/16 inch
Rod Resistance: 109 pounds.
Material: Solid Brass
Includes 3 Strike Plates
Packaged with all mounting hardware

Colors Available:

Polished Brass
Antique Brass
Oil-Rubbed Bronze
Brushed/Satin Nickel
Antique Nickel (Pewter)
Flat Black
Brushed/Satin Chrome
Polished Chrome
Lifetime Polished Brass (PVD)
