Winslow Active Keyed Multipoint Lock Trim Wave Lever Schlage 5 Pin Keyway
Part Number: Price: $179.95 to $209.51Premium multipoint lock handleset for use with tongue Multipoint lock only
Will NOT work work with the Triple latch
Application: Residential exterior door with Rockwell multipoint lock.
Function: Active Keyed door
Style: 2 Piece sectional Grip Handleset
Deadbolt Plate Width: 2.75 inches
Deadbolt Plate Length: 4 inches
Entrance Handle Plate Width: 2.75 inches
Entrance Handle Plate length: 5 inches
Handleset Style: Modern Rectangular escutcheon plates
Lever Style: curved lever, classic wave design
Material: solid forged brass
Bore Application: 5-1/2 inch, center of holes for Handleset and Deadbolt
Cross Bore: 2-1/8\" Diameter, Standard for most doors
Door Thickness: 1-3/4 inch
Keyway: Schlage SC1, 5 pin
Keys: 2 with Large Bow head
Will NOT work work with the Triple latch
Application: Residential exterior door with Rockwell multipoint lock.
Function: Active Keyed door
Style: 2 Piece sectional Grip Handleset
Deadbolt Plate Width: 2.75 inches
Deadbolt Plate Length: 4 inches
Entrance Handle Plate Width: 2.75 inches
Entrance Handle Plate length: 5 inches
Handleset Style: Modern Rectangular escutcheon plates
Lever Style: curved lever, classic wave design
Material: solid forged brass
Bore Application: 5-1/2 inch, center of holes for Handleset and Deadbolt
Cross Bore: 2-1/8\" Diameter, Standard for most doors
Door Thickness: 1-3/4 inch
Keyway: Schlage SC1, 5 pin
Keys: 2 with Large Bow head
